RENOGY REGO 12V AC-DC 35A Battery Charger
RENOGY REGO 12V AC-DC 35A Battery Charger
Couldn't load pickup availability
5A AC-DC Battery Charger is your reliable solution for off-grid power management. Engineered for RVs, marine vessels, cabins, and remote solar installations, this intelligent charger combines advanced 4-stage charging technology with universal battery compatibility. Supports lithium (LiFePO₄), AGM, GEL, flooded lead acid, and custom battery profiles. The adaptive charging algorithm—bulk, boost, float, and equalization stages—maximizes battery lifespan while comprehensive safety protections guard against over-voltage, over-current, temperature extremes, short circuits, and reverse polarity. Compact and versatile, it mounts vertically or horizontally with minimal clearance requirements (150mm minimum on all sides). Includes AC power cable, battery temperature sensor, mounting hardware, and user manual.
| Specification | Details |
|---|---|
| Model | RACC35A1W |
| Output Current | Max 35A |
| Input Voltage | 180–264V AC (45–65Hz) |
| Output Voltage | 9–17V DC |
| Charging Type | Adaptive 4-stage |
| Operating Temperature | -20°C to 60°C (-4°F to 140°F) |
| Dimensions | 228 x 160 x 72 mm (8.98" x 6.3" x 2.83") |
| Weight | < 3 kg (6.61 lbs) |
| Protection Rating | IP32 |
