The 60A DC to DC Battery Charger is the most effective way to charge your house/secondary batteries from the starter battery. Compatible with a multitude of alternator types, the DC-DC battery charger offers correct charging for AGM, Flooded, Gel, and Lithium deep cycle batteries. 3-stage battery charger ensures batteries are being charged optimally and automatically.
KEY FEATURES
Compatible Multiple Battery Types - Compatible with a multitude of alternator types, the DC-DC battery charger offers correct charging for AGM, Flooded, Gel, and Lithium batteries.
Various Protections For Ultra Safety - The DC-DC battery charger isolates the input and output to prevent voltage transmission errors and interfere with house battery charging. It has multifunctional safety technology including over-voltage protection, over-temperature protection, and reverse polarity protection to make it safer for use.
Protect Your Starter Battery - This Renogy DC-DC battery charger is compatible with traditional and smart alternators. The D+ Ignition cable is capable of identifying whether the generator is started, to prevent over-discharge of the starting battery and protect the generator. 18-16AWG copper cable recommended. Please note the D+ Ignition Cable is not included.
Smart 3-stage Charging - The DC-DC battery charger will charge your house batteries from the starter battery by 3-stage charging (Bulk, Boost, and Float), to make sure it optimally and automatically charge to 100%.
Protect Your House Battery - The LC wire can automatically adjust the charging current to prevent excessive charging current from damaging the house battery. 18-16AWG copper cable recommended. Please note the LC cable is not included. Compact, sturdy design, built tough for all conditions.
SPECIFICATION
| RENOGY 60A DC TO DC BATTERY CHARGER |
|
| Nominal Voltage: 12V |
Rated Charge Current: 60A |
| Output: 750W
|
Idle Power Consumption: <0.4 A
|
| Input Voltage Range: 8V-16V |
Equalization Voltage: N/A |
| Float Voltage: 13.2-13.8V |
Boost Voltage: 14.1-14.7V |
| Operating Temperature: -20°C to +50°C |
Weight: 2.40 kg. / 5.29 lbs
|
| Dimensions: 311 x 175 x 68 mm / 12.2 x 6.9 x 2.7 in
|
Terminals: M8 X 10mm, 1mm thread pitch
|
| Certifications： |
|
| CE |
YES |
| ROHS |
YES |
