12V 200Ah Lithium Iron Phosphate Battery w/ Bluetooth
12V 200Ah Lithium Iron Phosphate Battery w/ Bluetooth
Couldn't load pickup availability
The Renogy 200Ah Lithium Battery w/ Bluetooth is designed for the drop-in replacement of deep-cycle lead-acid batteries with its standard BCI group size. Weighing only half of the lead-acid counterparts, the 200Ah lithium battery can be safely discharged to 100% DOD (Depth of Discharge), delivering twice the energy. Manufactured with automotive grade battery cells, the battery features the highest safety standards and an extended cycle life. Hosting intelligent software, the advanced BMS (Battery Management System) provides comprehensive protection to the 200Ah lithium battery. The built-in Bluetooth module enables remote monitoring on mobile devices in real time.
KEY FEATURES
Uncompromising Quality - State-of-the-art battery cells ensure a lifespan of more than 2000 cycles, 200A continuous discharge current, and a wide operating temperature range.
Easy Upgrades - Upgrades to lithium seamlessly with the standard BCI group size but a greater energy density, a deeper discharge capability, a higher round-trip efficiency, and a faster charging speed.
Reliable BMS System - The state-of-the-art battery management system (BMS) with high-performance dual-processors provides short circuit, over charging and over-temperature protection while maintaining a balanced voltage across all cells.
Auto-balancing Function - Easily connect multiple batteries in parallel with the auto-balancing function, improving the average charging efficiency for your batteries in the long term. Real-time monitor Monitors the battery operation status on mobile devices in real time with the built-in Bluetooth module.
SPECIFICATION
|
RENOGY 12V 200AH LITHIUM IRON PHOSPHATE BATTERY W/ BLUETOOTH |
|||
|---|---|---|---|
| Operation Specifications | Mechanical Specifications | ||
| Rated Capacity | 200AH | Dimensions | 20.55 x 9.45 x 8.62 inch (522 x 240 x 219 mm) |
| Nominal Voltage | 12.8V | Weight | 60.2 lbs. (27.3 kg) |
| Voltage Range | 10~14.8 V | Charge Temperature | 32~131°F/ 0~55°C |
| Cycle Life(0.2C,25℃) | 80%DOD 2000 Cycles | Discharge Temperature | -4~140°F/ -20~60°C |
| Maximum Continuous Charging Current | 100 A | Protection Rate | IP65 |
| Maximum Continuous Discharging Current | 200 A | Communication Protocol | Modbus |
| Standard Operation Temperature | 25℃±5℃ | Certifications | |
| Storage Temperature | -13~149℉ / -25~65℃ | UN38.3 | YES |
| Connection Method | Parallel | MSDS | YES |
| FCC | YES | ||
| Accessories | PSE | YES | |
| M8 Bolts | x 2 | UKCA | YES |
| CE | YES | ||
Notes:
DO NOT string the battery in series.
ONLY connect batteries of the same manufacturer and model in parallel.
DO NOT connect more than 8 batteries in parallel.
Secure all cable connections to proper specification in order to ensure good connections between the cable lugs and the battery terminals.
Avoid too high a voltage difference between paralleled batteries, despite the auto-balancing function, to avoid triggering the over-current protection.
The battery is shipped in shelf mode. Before using the battery for the first time, please activate the battery with a charge/discharge current greater than 1A and measure the terminal voltage to validate.
